Written by Whitney Clavin
NASA’s Jet Propulsion Laboratory
Pasadena, CA – Entangled by gravity and destined to merge, two candidate black holes in a distant galaxy appear to be locked in an intricate dance.
Researchers using data from NASA’s Galaxy Evolution Explorer (GALEX) and NASA’s Hubble Space Telescope have come up with the most compelling confirmation yet for the existence of these merging black holes and have found new details about their odd, cyclical light signal.
The candidate black hole duo, called PG 1302-102, was first identified earlier this year using ground-based telescopes.The black holes are the tightest orbiting pair detected so far, with a separation not much bigger than the diameter of our solar system.
They are expected to collide and merge in less than a million years, triggering a titanic blast with the power of 100 million supernovae.
Researchers are studying this pair to better understand how galaxies and the monstrous black holes at their cores merge — a common occurrence in the early universe. But as common as these events were, they are hard to spot and confirm.
PG 1302-102 is one of only a handful of good binary black hole candidates. It was discovered and reported earlier this year by researchers at the California Institute of Technology in Pasadena, after they scrutinized an unusual light signal coming from the center of a galaxy.
The researchers, who used telescopes in the Catalina Real-Time Transient Survey, demonstrated that the varying signal is likely generated by the motion of two black holes, which swing around each other every five years. While the black holes themselves don’t give off light, the material surrounding them does.
In the new study, published in the September 17th issue of Nature, researchers found more evidence to support and confirm the close-knit dance of these black holes. Using ultraviolet data from GALEX and Hubble, they were able to track the system’s changing light patterns over the past 20 years.
“We were lucky to have GALEX data to look through,” said co-author David Schiminovich of Columbia University in New York. “We went back into the GALEX archives and found that the object just happened to have been observed six times.”
Hubble, which sees ultraviolet light in addition to visible and other wavelengths of light, had likewise observed the object in the past.
The ultraviolet light was important to test a prediction of how the black holes generate a cyclical light pattern. The idea is that one of the black holes in the pair is giving off more light — it is gobbling up more matter than the other one, and this process heats up matter that emits energetic light. As this black hole orbits around its partner every five years, its light changes and appears to brighten as it heads toward us.
What’s causing the changes in light? One set of changes has to do with the “blue shifting” effect, in which light is squeezed to shorter wavelengths as it travels toward us in the same way that a police car’s siren squeals at higher frequencies as it heads toward you. Another reason has to do with the enormous speed of the black hole.
The brighter black hole is, in fact, traveling at nearly seven percent the speed of light — in other words, really fast. Though it takes the black hole five years to orbit its companion, it is traveling vast distances.
It would be as if a black hole lapped our entire solar system from the outer fringes, where the Oort cloud of comets lies, in just five years. At speeds as high as this, which are known as relativistic, the light becomes boosted and brighter.
D’Orazio and colleagues modeled this effect based on a previous Caltech paper and predicted how it should look in ultraviolet light. They determined that, if the periodic brightening and dimming previously seen in the visible light is indeed due to the relativistic boosting effect, then the same periodic behavior should be present in ultraviolet wavelengths, but amplified 2.5 times. Sure enough, the ultraviolet light from GALEX and Hubble matched their predictions.
“We are strengthening our ideas of what’s going on in this system and starting to understand it better,” said Zoltan Haiman, a co-author from Columbia University who conceived the project.
The results will also help researchers understand how to find even closer-knit merging black holes in the future, what some consider the holy grail of physics and the search for gravitational waves. In the final moments before the ultimate union of two black holes, when they are tightly spinning around each other like ice skaters in a “death spiral,” they are predicted to send out ripples in space and time. These so-called gravitational waves, whose existence follows from Albert Einstein’s gravity theory published 100 years ago, hold clues about the fabric of our universe.
The California Institute of Technology in Pasadena led the Galaxy Evolution Explorer mission, which ended in 2013 after more than a decade of scanning the skies in ultraviolet light. NASA’s Jet Propulsion Laboratory, also in Pasadena, managed the mission and built the science instrument. JPL is managed by Caltech for NASA.
The Hubble Space Telescope is a project of international cooperation between NASA and ESA (European Space Agency). NASA’s Goddard Space Flight Center in Greenbelt, Maryland, manages the telescope. The Space Telescope Science Institute (STScI) in Baltimore, Maryland, conducts Hubble science operations. STScI is operated for NASA by the Association of Universities for Research in Astronomy in Washington.
