Written by Preston Dyches
NASA’s Jet Propulsion Laboratory
Pasadena, CA – NASA scientists have identified an unexpected high-altitude methane ice cloud on Saturn’s moon Titan that is similar to exotic clouds found far above Earth’s poles.
This lofty cloud, imaged by NASA’s Cassini spacecraft, was part of the winter cap of condensation over Titan’s north pole. Now, eight years after spotting this mysterious bit of atmospheric fluff, researchers have determined that it contains methane ice, which produces a much denser cloud than the ethane ice previously identified there.“The idea that methane clouds could form this high on Titan is completely new,” said Carrie Anderson, a Cassini participating scientist at NASA’s Goddard Space Flight Center in Greenbelt, Maryland, and lead author of the study. “Nobody considered that possible before.”
Methane clouds were already known to exist in Titan’s troposphere, the lowest layer of the atmosphere. Like rain and snow clouds on Earth, those clouds form through a cycle of evaporation and condensation, with vapor rising from the surface, encountering cooler and cooler temperatures and falling back down as precipitation. On Titan, however, the vapor at work is methane instead of water.
The newly identified cloud instead developed in the stratosphere, the layer above the troposphere. Earth has its own polar stratospheric clouds, which typically form above the North Pole and South Pole between 49,000 and 82,000 feet (15 to 25 kilometers) — well above cruising altitude for airplanes. These rare clouds don’t form until the temperature drops to minus 108 degrees Fahrenheit (minus 78 degrees Celsius).
Other stratospheric clouds had been identified on Titan already, including a very thin, diffuse cloud of ethane, a chemical formed after methane breaks down. Delicate clouds made from cyanoacetylene and hydrogen cyanide, which form from reactions of methane byproducts with nitrogen molecules, also have been found there.
But methane clouds were thought unlikely in Titan’s stratosphere. Because the troposphere traps most of the moisture, stratospheric clouds require extreme cold. Even the stratosphere temperature of minus 333 degrees Fahrenheit (minus 203 degrees Celsius), observed by Cassini just south of the equator, was not frigid enough to allow the scant methane in this region of the atmosphere to condense into ice.
What Anderson and her Goddard co-author, Robert Samuelson, noted is that temperatures in Titan’s lower stratosphere are not the same at all latitudes. Data from Cassini’s Composite Infrared Spectrometer and the spacecraft’s radio science instrument showed that the high-altitude temperature near the north pole was much colder than that just south of the equator.
Other factors support the methane identification. Initial observations of the cloud system were consistent with small particles composed of ethane ice. Later observations revealed some regions to be clumpier and denser, suggesting that more than one ice could be present.
The team confirmed that the larger particles are the right size for methane ice and that the expected amount of methane — one-and-a-half percent, which is enough to form ice particles — is present in the lower polar stratosphere.
The mechanism for forming these high-altitude clouds appears to be different from what happens in the troposphere. Titan has a global circulation pattern in which warm air in the summer hemisphere wells up from the surface and enters the stratosphere, slowly making its way to the winter pole. There, the air mass sinks back down, cooling as it descends, which allows the stratospheric methane clouds to form.
“Cassini has been steadily gathering evidence of this global circulation pattern, and the identification of this new methane cloud is another strong indicator that the process works the way we think it does,” said Michael Flasar, Goddard scientist and principal investigator for Cassini’s Composite Infrared Spectrometer (CIRS).
Like Earth’s stratospheric clouds, this methane cloud was located near the winter pole, above 65 degrees north latitude. Anderson and Samuelson estimate that this type of cloud system — which they call subsidence-induced methane clouds, or SIMCs for short — could develop between 98,000 to 164,000 feet (30 to 50 kilometers) in altitude above Titan’s surface.
“Titan continues to amaze with natural processes similar to those on the Earth, yet involving materials different from our familiar water,” said Scott Edgington, Cassini deputy project scientist at NASA’s Jet Propulsion Laboratory in Pasadena, California. “As we approach southern winter solstice on Titan, we will further explore how these cloud formation processes might vary with season.”
The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. JPL, a division of the California Institute of Technology, Pasadena, manages the mission for NASA’s Science Mission Directorate in Washington.
The CIRS team is based at Goddard. The radio science team is based at JPL.
